Reveal Ceiling Collection
Core Composition
RealCore™
Color
Amber or Natural
Material
100% Bamboo
Size
3/4” x 473/4” x 953/4“
Metric
19mm x 1213mm x 2432mm
Weight
90 lbs
Surface Texture
Prefinished or Unfinished
Fire Resistance Classification
Class C (Class B available)
Emissions Testing: ASTM-D6007
*Meets or surpasses ULEF (ultra low emitting formaldehyde) standards under CARB ll.
Core Composition
RealCore™
Color
Amber or Natural
Material
100% Bamboo
Size
3/4” x 473/4” x 953/4“
Metric
19mm x 1213mm x 2432mm
Weight
90 lbs
Surface Texture
Prefinished or Unfinished
Fire Resistance Classification
Class C (Class B available)
Emissions Testing: ASTM-D6007
*Meets or surpasses ULEF (ultra low emitting formaldehyde) standards under CARB ll.
Core Composition
RealCore™
Color
Amber or Natural
Material
100% Bamboo
Size
3/4” x 473/4” x 953/4“
Metric
19mm x 1213mm x 2432mm
Weight
90 lbs
Surface Texture
Prefinished or Unfinished
Fire Resistance Classification
Class C (Class B available)
Emissions Testing: ASTM-D6007
*Meets or surpasses ULEF (ultra low emitting formaldehyde) standards under CARB ll.
Core Composition
RealCore™
Color
Amber or Natural
Material
100% Bamboo
Size
3/4” x 473/4” x 953/4“
Metric
19mm x 1213mm x 2432mm
Weight
90 lbs
Surface Texture
Prefinished or Unfinished
Fire Resistance Classification
Class C (Class B available)
Emissions Testing: ASTM-D6007
*Meets or surpasses ULEF (ultra low emitting formaldehyde) standards under CARB ll.
Core Composition
RealCore™
Color
Amber or Natural
Material
100% Bamboo
Size
3/4” x 473/4” x 953/4“
Metric
19mm x 1213mm x 2432mm
Weight
90 lbs
Surface Texture
Prefinished or Unfinished
Fire Resistance Classification
Class C (Class B available)
Emissions Testing: ASTM-D6007
*Meets or surpasses ULEF (ultra low emitting formaldehyde) standards under CARB ll.
Core Composition
RealCore™
Color
Amber or Natural
Material
100% Bamboo
Size
3/4” x 473/4” x 953/4“
Metric
19mm x 1213mm x 2432mm
Weight
90 lbs
Surface Texture
Prefinished or Unfinished
Fire Resistance Classification
Class C (Class B available)
Emissions Testing: ASTM-D6007
*Meets or surpasses ULEF (ultra low emitting formaldehyde) standards under CARB ll.
Core Composition
RealCore™
Color
Amber or Natural
Material
100% Bamboo
Size
3/4” x 473/4” x 953/4“
Metric
19mm x 1213mm x 2432mm
Weight
90 lbs
Surface Texture
Prefinished or Unfinished
Fire Resistance Classification
Class C (Class B available)
Emissions Testing: ASTM-D6007
*Meets or surpasses ULEF (ultra low emitting formaldehyde) standards under CARB ll.
Plyboo Ceilings are compatible with a wide variety of ceiling types and conditions:
- Screw Installation: Install directly to substrate, mount on furring, or screw to bottom flange of suspended metal ceiling grid. Self-drilling screws with small heads fit between ribs of Linear and Linear Sound panels to semi-conceal fasteners without countersinking.
- Direct Hanging: Suspension wires can be semi-concealed in the ribs of Linear Sound panels allowing installation of panels without a metal ceiling grid.
- Exposed, Semi-Exposed, and Concealed Metal Ceiling Grid: Use square edges for lay-in installation in exposed grid, or routed edges for lift-and-shift installation with narrow reveals or butt joints.
- C-Clips are attached to upper side of panels and hook over ceiling grids or other supports.
- Plyboo panels are available in sizes up to 4 x 10 ft (1.2 x 3m), ½ or ¾ inch (13mm or 19mm) thicknesses, and with Class B or Class C surface burning characteristics; check with factory or local representative for availability. Plyboo ceiling panels are more durable than conventional acoustic ceiling products, easy to maintain, and complement Plyboo used for wall panels, furniture, and flooring.
